Horizontal saws (2025)

Horizontal saws for the flexible
production of aluminum panels

Maximum precision with minimum cutting gap: Our horizontal saws save material and cycle time, reduce rework and increase efficiency - get more out of every block!

With the Mössner AluPlate Master series, Mössner offers innovative and flexible solutions for efficient aluminum plate production. Our horizontal saws impress with their versatility and are available in various performance classes, with a drive power of up to 110 kW. This allows aluminum blocks with a width of up to 3,200 mm to be processed. Thanks to the sturdy steel construction and generously dimensioned running wheels, the saw bands are protected, resulting in a longer service life and excellent cutting results. Numerous options and expansion possibilities make the saws perfectly customisable to your individual production requirements.

Opt for precision, durability and efficiency – Mössner horizontal saws get the best out of every aluminum block!

Driver Power: 55 kw


Impeller: 1.100 mm
Saw band width: 54 mm

Workpiece size:


Length: 4.000 mm
Width: 1.700 mm
Height: 1.200 mm

Option 1


Table extension to workpiece size:
Length: 6.000 mm
Width: 1.700 mm
Height: 1.200 mm

Driver Power: 75 kw


Impeller: 1.100 mm
Saw band width: 54 mm

Workpiece size:


Length: 4.000 mm
Width: 2.200 mm
Height: 1.200 mm

Option 1


Table extension to workpiece size:
Length: 6.000 mm
Width: 2.200 mm
Height: 1.200 mm

Driver Power: 90 kw


Impeller: 1.500 mm
Saw band width: 80 mm

Workpiece size:


Length: 4.000 mm
Width: 2.700 mm
Height: 1.200 mm

Option 1


Table extension to workpiece size:
Length: 6.000 mm
Width: 2.700 mm
Height: 1.200 mm

Driver Power: 110 kw


Impeller: 1.500 mm
Saw band width: 80 mm

Workpiece size:


Length: 4.000 mm
Width: 3.200 mm
Height: 1.200 mm

Option 1


Table extension to workpiece size:
Length: 6.000 mm
Width: 3.200 mm
Height: 1.200 mm

Our saws can be extended by:

  • Automated loading
  • Suction system
  • Panel cleaning with brush
  • Automated unloading
  • Panel thickness measurement
  • Roughness measurement of the panel
  • Weighing technology for determining the panel weight
  • Automated panel labelling
  • Chip press
  • Noise protection cabin
  • Camera system
